- Ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion
- Billet Compressor Wheel with Extended Tapered Tip Technology
- Inconel 713c 11 Blade Turbine Wheel
- V-Band Flange kit for the exhaust housing included
- Max Engine Horsepower: 1600
- T4 Divided 1.28
Description
- Billet Compressor Wheel: 80.8 x 110.5mm, 7+7 Blade
- Turbine Wheel: 85 x 89.5mm, 11 Blade
- Bearing System: Dual Ball Bearing (provides optimal turbo response & better durability by reducing the shaft-motion)
- Compressor Cover：4.0” Hose Inlet/3″ V-Band Outlet
- Turbine Housing: T4 Divided 1.28A/R; Dual V-Band 1.15A/R, 1.28A/R(Coming Soon)
- The internal oil feed port is 0.9mm(Oil restrictor is no needed)
- Oil feed fitting: 1/8-27 NPSF(Drawing)
- Oil Drain: -12AN
