- Ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion
- Billet Compressor Wheel with Extended Tapered Tip Technology
- Inconel 713c 10 Blade Turbine Wheel
- V-Band Flange kit for the exhaust housing included
- Max Engine Horsepower: 900
Description
- Billet Compressor Wheel: 64.4mm / 82.2mm / 87.1mm, 7+7 Blade
- Turbine Wheel: 66.1 / 74.17mm, 10 Blade
- Bearing System: Dual Ball Bearing (provides optimal turbo response & better durability by reducing the shaft-motion)
- Compressor Cover Inlet/Outlet: 4.0” / 2.5” Hose
- Turbine Housing: T3 0.63A/R,T3 0.82A/R, T4 0.96A/R
- Internal oil feed port is 0.9mm
- Oil feed fitting: 1/8-27 NPSF(Drawing)
- Oil drain: T4 flange(Drawing)
Oil Drain Fitting:
